HYDEX® 4101 & 4101L (lubricated) is a very stable chemical compound that can withstand high impact without deterioration. It is approved for direct contact with food by the FDA and is ideal for machined parts in food processing equipment. HYDEX™ 4101 has excellent resistance to typical cleaning chemicals such as chlorine and caustic solutions and has a very low moisture absorption rate, as much as 15 times less than nylon.
- Good chemical resistance properties
- High impact strength
- A wear factor up to 50% better then PET-P
- Very low moisture absorption rate
- Excellent machining qualities
- No center line porosity
HYDEX® 4101 & 4101L (lubricated) exhibits a broad range of outstanding properties for a variety of applications, especially in the food processing industry. It is ideal for applications such as cams, bearings, gears, food pistons, wear strips, scraper blades, valve bodies and conveyor components.
| Properties | Condition | Value | Test Method | Comment | ||
|---|---|---|---|---|---|---|
| Mechanical | Modulus of elasticity (tensile test) | @ 73°F | 425,000 | psi | ASTM D 638 | |
| Tensile strength | @ 73°F | 9,400 | psi | ASTM D 638 | ||
| Elongation at break | @ 73°F | 50 | % | ASTM D 638 | ||
| Modulus of elasticity (flexural test) | @ 73°F | 420,000 | psi | ASTM D 790 | ||
| Impact strength (Izod) | 0.7 | ft-lbs/in | ASTM D 256 | |||
| Coefficient of friction | Static | 0.19 | 1) | 1) per LNP EPALP-TB001 | ||
| Coefficient of friction | Dynamic, 40 psi, 50 fpm | 0.25 | 1) | |||
| Wear rate | @2000 PV | 210 | in3-min/ft-lbs-hr | 1) | ||
| Thermal | Deflection temperature | @ 264 psi | 200 | °F | ASTM D 648 | |
| Service temperature | Long Term | 221 | °F | – | ||
| Other | Limiting PV | @ 100 fpm | 6,000 | psi-fpm | 2) | 2) per LNP EPALP-TB003 |
| Moisture absorption | @ 24 hrs, 73°F | 0.07 | % | ASTM D 570 | ||
| This information is only to assist and advise you on current technical knowledge and is given without obligation or liability. All trade and patent rights should be observed. All rights reserved. Data obtained from extruded shapes material. HYDEX® – Ensinger Industries, Inc. |
||||||
Mechanical
Property: Modulus of elasticity (tensile test)
Condition: @ 73°F
Value: 425,000 psi
Test Method: ASTM D 638
Comment: –
Property: Tensile strength
Condition: @ 73°F
Value: 9,400 psi
Test Method: ASTM D 638
Comment: –
Property: Elongation at break
Condition: @ 73°F
Value: 50 %
Test Method: ASTM D 638
Comment: –
Property: Modulus of elasticity (flexural test)
Condition: @ 73°F
Value: 420,000 psi
Test Method: ASTM D 790
Comment: –
Property: Impact strength (Izod)
Condition: –
Value: 0.7 ft-lbs/in
Test Method: ASTM D 256
Comment: –
Property: Coefficient of friction
Condition: Static
Value: 0.19 –
Test Method: 1)
Comment: 1) per LNP EPALP-TB001
Property: Coefficient of friction
Condition: Dynamic, 40 psi, 50 fpm
Value: 0.25 –
Test Method: 1)
Comment: –
Property: Wear rate
Condition: @2000 PV
Value: 210 in3-min/ft-lbs-hr
Test Method: 1)
Comment: –
Thermal
Property: Deflection temperature
Condition: @ 264 psi
Value: 200 °F
Test Method: ASTM D 648
Comment: –
Property: Service temperature
Condition: Long Term
Value: 221 °F
Test Method: –
Comment: –
Other
Property: Limiting PV
Condition: @ 100 fpm
Value: 6,000 psi-fpm
Test Method: 2)
Comment: 2) per LNP EPALP-TB003
Property: Moisture absorption
Condition: @ 24 hrs, 73°F
Value: 0.07 %
Test Method: ASTM D 570
Comment: –
This information is only to assist and advise you on current technical knowledge and is given without obligation or liability. All trade and patent rights should be observed. All rights reserved. Data obtained from extruded shapes material. HYDEX® – Ensinger Industries, Inc.
