TECATRON PPS is a high performance thermoplastic that combines good mechanical properties with excellent thermal and chemical resistance properties. There is no known solvent that dissolves TECATRON PPS at temperatures below 392°F. Its low ionic impurities make it an excellent choice for applications where high purity is a concern. TECATRON GF40 is a glass reinforced material that offers extremely high strength along with excellent chemical resistance properties. TECATRON PVX is a bearing grade PPS that is suitable for high load applications.
- High purity characteristics
Low ionic impurities are apparent. - Outstanding retention of mechanical properties under continuous use up to 338°F (170°C)
- Excellent chemical resistance
- Good electrical insulator
- High mechanical strength
- High strength-to-weight ratio
- Corrosion resistant
- Dimensional stability over wide variations of temperature and moisture
- Creep resistance
Long-term property retention.
TECATRON PPS’s excellent thermal and chemical resistance along with its ionic impurities make an excellent choice for applications requiring low outgassing and high purity. TECATRON PPS is typically used in the automotive, electrical/ electronic, industrial, mechanical, appliance and semiconductor industries.
| Properties | Condition | Value | Test Method | Comment | ||
|---|---|---|---|---|---|---|
| Mechanical | Weak (K) factor | Against Steel, 40 psi, 50 fpm | 540*10*-10 | in3-min/ft-lbs-hr | ASTM D 3702 | |
| Modulus of elasticity (tensile test) | @ 73 °F | 731,500 | psi | ASTM D 638 | ||
| Tensile strength at yield | @ 73 °F | 15,000 | psi | ASTM D 638 | ||
| Elongation at break | @ 73 °F | 10 | % | ASTM D 638 | ||
| Flexural Strength | @ 73 °F | 24,000 | psi | ASTM D 790 | ||
| Modulus of Elasticity (flexural test) | @ 73 °F | 622,000 | psi | ASTM D 790 | ||
| Compression strength | @ 10% strain | 17,800 | psi | ASTM D 695 | ||
| Compression modulus | 367,000 | psi | ASTM D 695 | |||
| Impact Strength (Izod) | @ 73°F | .52 | ft-lbs/in | ASTM D 256 | ||
| Rockwell Hardness | @ 73°F, M Scale | 102 | ASTM D 785 | |||
| Coefficient of Friction | Dynamic, 40 psi, 50 fpm | 0.24 | ASTM S 3702 | |||
| Thermal | Melting temperature | 540 | °F | ASTM D 2133 | (1) per UL746B | |
| Deflection temperature | @ 264 psi | 220 | °F | ASTM S 648 | ||
| Deflection temperature | @ 66 psi | 400 | °F | ASTM D 648 | ||
| Service temperature | Long term | 338 | °F | – (1) | ||
| Service temperature | Intermittent | 500 | °F | – | ||
| Thermal expansion (CLTE) | 3.3*10-5 | in/in/°F | ASTM D 696 | |||
| Specific heat | 0.239 | BTU/lb-°F | – | |||
| Thermal conductivity | 2.08 | BTU-in/hr-ft2-°F | – | |||
| Electrical | Volume resistivity | 1.0*1015 | Ω*cm | ASTM D 257 | ||
| Dielectric Strength | 450 | V/mil | ASTM D 149 | |||
| Dissipation factor | @ 1KHz, 73°F | .0001 | ASTM D 150 | |||
| Dielectric constant | @ 1KHz, 73°F, 50% RH | 3.0 | ASTM D 150 | |||
| Other | Moisture absorption | @ 24 hrs, 73 °F | 0.02 | % | ASTM D 570 | |
| Flammability (UL94) | V-0 | – | ||||
| This information is only to assist and advise you on current technical knowledge and is given without obligation or liability. All trade and patent rights should be observed. All rights reserved. Data obtained from extruded shapes material. TECATRON®PPS – Ensinger Industries, Inc. |
||||||
Mechanical
Property: Weak (K) factor
Condition: Against Steel, 40 psi, 50 fpm
Value: 540*10*-10 in3-min/ft-lbs-hr
Test Method: ASTM D 3702
Comment: –
Property: Modulus of elasticity (tensile test)
Condition: @ 73 °F
Value: 731,500 psi
Test Method: ASTM D 638
Comment: –
Property: Tensile strength at yield
Condition: @ 73 °F
Value: 15,000 psi
Test Method: ASTM D 638
Comment: –
Property: Elongation at break
Condition: @ 73 °F
Value: 10 %
Test Method: ASTM D 638
Comment: –
Property: Flexural Strength
Condition: @ 73 °F
Value: 24,000 psi
Test Method: ASTM D 790
Comment: –
Property: Modulus of Elasticity (flexural test)
Condition: @ 73 °F
Value: 622,000 psi
Test Method: ASTM D 790
Comment: –
Property: Compression strength
Condition: @ 10% strain
Value: 17,800 psi
Test Method: ASTM D 695
Comment: –
Property: Compression modulus
Condition: –
Value: 367,000 psi
Test Method: ASTM D 695
Comment: –
Property: Impact Strength (Izod)
Condition: @ 73°F
Value: .52 ft-lbs/in
Test Method: ASTM D 256
Comment: –
Property: Rockwell Hardness
Condition: @ 73°F, M Scale
Value: 102 –
Test Method: ASTM D 785
Comment: –
Property: Coefficient of Friction
Condition: Dynamic, 40 psi, 50 fpm
Value: 0.24 –
Test Method: ASTM S 3702
Comment: –
Thermal
Property: Melting temperature
Condition: –
Value: 540 °F
Test Method: ASTM D 2133
Comment: (1) per UL746B
Property: Deflection temperature
Condition: @ 264 psi
Value: 220 °F
Test Method: ASTM S 648
Comment: –
Property: Deflection temperature
Condition: @ 66 psi
Value: 400 °F
Test Method: ASTM D 648
Comment: –
Property: Service temperature
Condition: Long term
Value: 338 °F
Test Method: – (1)
Comment: –
Property: Service temperature
Condition: Intermittent
Value: 500 °F
Test Method: –
Comment: –
Property: Thermal expansion (CLTE)
Condition: –
Value: 3.3*10-5 in/in/°F
Test Method: ASTM D 696
Comment: –
Property: Specific heat
Condition: –
Value: 0.239 BTU/lb-°F
Test Method: –
Comment: –
Property: Thermal conductivity
Condition: –
Value: 2.08 BTU-in/hr-ft2-°F
Test Method: –
Comment: –
Electrical
Property: Volume resistivity
Condition: –
Value: 1.0*1015 Ω*cm
Test Method: ASTM D 257
Comment: –
Property: Dielectric Strength
Condition: –
Value: 450 V/mil
Test Method: ASTM D 149
Comment: –
Property: Dissipation factor
Condition: @ 1KHz, 73°F
Value: .0001 –
Test Method: ASTM D 150
Comment: –
Property: Dielectric constant
Condition: @ 1KHz, 73°F, 50% RH
Value: 3.0 –
Test Method: ASTM D 150
Comment: –
Other
Property: Moisture absorption
Condition: @ 24 hrs, 73 °F
Value: 0.02 %
Test Method: ASTM D 570
Comment: –
Property: Flammability (UL94)
Condition: –
Value: V-0 –
Test Method: –
Comment: –
This information is only to assist and advise you on current technical knowledge and is given without obligation or liability. All trade and patent rights should be observed. All rights reserved. Data obtained from extruded shapes material. TECATRON®PPS – Ensinger Industries, Inc.
